Water Based Glue Laminating Machine for Shoe Materials
The water-based glue laminating machine adopts water-based glue/white latex glue to laminate fabric with fabric, fabric with foam, fabric with EVA, fabric with leather, and more. It is widely used in the shoe industry, bag/luggage industry, garment industry, carpet industry, football industry, bra cup industry, interior decoration, and car interiors.
Machine Features
Eco-Friendly and Cost-Effective Lamination Process
The machine uses water-based glue/white latex glue, ensuring not only a more environmentally friendly and sustainable lamination process but also resulting in a higher-quality end product. The use of water-based glue also leads to cost savings, making the machine a smart investment for your business.
Reliable Vertical Structure
The machine's vertical structure offers a low failure rate and long service life. This ensures reliable and consistent performance, minimizing downtime and maximizing productivity.
Equipped with a Heat-Resistant Mesh Belt
The high-quality heat-resistant mesh belt allows laminated materials to stay in close contact with the drying roller. This improves drying efficiency, resulting in laminated products that are soft, washable, and more durable, with enhanced adhesive strength. The end products are not only high-quality but also long-lasting.
Heating Roller Coated with Teflon Paper
The surface of the heating roller is coated with Teflon paper, effectively preventing the water-based adhesive from sticking to the roller surface or carbonizing. Over time, users only need to replace the Teflon paper instead of the drying roller, making this an economical solution.
Automatic Infrared Centering Control
The machine is equipped with an automatic infrared centering control unit, which effectively prevents the mesh belt from deviating and ensures a longer service life for the belt.
Counting and Rewinding Units
The machine is also equipped with counting and rewinding units. The water-based glue laminating machine is easy to maintain, with low maintenance costs.
Main Machine Parameters (Customizable)
Modell | KT-WF-1800 |
---|---|
Machine Roller Width
| 1800 mm |
Gluing Amount
| About 50g/m2 |
Machine speed
| 5-45 m/min |
Power | 45,0 kW |
Electric Current and Voltage
| Customizable
|
Net Weight
| 4500 kg |
Dimension
| 6500 x 2400 x 2450 mm |
Maximum Material Width
| 1600 mm |
